Power Distribution Bus Strips and Power Connect Components

Clip: .008 Beryllium Copper half hard per QQ-C-533 heat treated full hard

Insulation:  Kynar Shrink Tubing per Mil-I-23053/8 Color: Blue. Insulator Tape meets Mil-I-15126

Plating:

G: Gold plate per Mil-G-45204 Type II, Class I, .000050 min. over nickel plate per QQ-N-290 Class I, .00010 min.

GS: Gold plate per Mil-G-45204 Type II, Class O, .000030 min. over nickel plate per QQ-N-290 Class I, .00010 min.

T : Bright Tin per Mil-T-10727 Type I .00010 min.

Contact Resistance: Less then 10 milliohms

Vibration: 4 hours sinusoidal cycling in each of three major orthogonial axis over the frequency range of 10 to 2000 to Hz at a double amplitude of .06 inch up to a limit value of 15G peak.

Contact Resistance After Vibration Test:  Less than 10 milliohms.

Insulation Resistance:  More than 100,000 megohms at 500 VDC for 60 seconds.

Thermal Shock:  3 cycles of 30 minutes each at – 65 degrees C and + 105 degrees C.

Humidity:  10 cycles for a total of 240 hours, between + 25 degrees C and + 65 degrees C relative humidity 80% to 98%.

Insulation Resistance After Humidity Test: 10,000 megohms minimum, at 500 VDC for 60 seconds

Durability:  No wear after 100 cycles with gold plated pin bar, contact resistance less than 10 milliohms
